KSGYR312F-L 3-Axis Fiber Optic Gyroscope 71.5×68×45mm ≤0.1°/h Bias

  • 1
  • 2

Dimensions : 71.5×68×45mm

Supply voltage : +5V

Weight : <320g

Brand Name : KACISE

Model Number : KSGYR312F-L

Certification : CE

Place of Origin : CHINA

MOQ : 1PCS

Supply Ability : 1000 Piece/Pieces per Week negotiable

Delivery Time : 5-8work days

Packaging Details : each unit has individual box and all boxes are packed in standard packages or customers requests available

Start time : ≤3s

Power dissipation (full temperature) : <4W

Bias (100s smooth, fix temperature) : ≤0.1°/h

Contact Now

KSGYR312F-L Three Axis Fiber Optic Gyroscope
Product Overview

This inertial angle rate sensor utilizes the optical Sagnac effect to measure rotational angular velocity along the sensitive axis. Its digital closed-loop detection circuit precisely extracts optical path differences caused by external angular speed, enabling real-time angular velocity signal detection through voltage signal modulation and feedback control.

The system consists of an optical angular velocity sensitive unit and signal detection components, providing triaxial angle increment data and internal temperature information.

Key Specifications
Attribute Value
Supply voltage +5V
Dimensions 71.5*68*45mm
Start time ≤3s
Bias (100s smooth, fix temperature) ≤0.1°/h
Power dissipation (full temperature) <4W
Weight <320g
Product Features
  • Precisely measures angular velocity of moving objects
  • All-solid-state design with no rotating or friction parts
  • Extended operational lifespan
  • Instantaneous startup capability
  • Simple, robust structure
  • Simultaneous three-axis angular velocity measurement
Applications
  • Photoelectric elevator systems
  • Flight control platforms
  • Strapdown inertial navigation
  • Optical and photographic instruments
  • Platform stabilizers
  • Inertial measurement instruments
KSGYR312F-L 3-Axis Fiber Optic Gyroscope 71.5×68×45mm ≤0.1°/h Bias
Technical Specifications
Performance Characteristics
Parameter Value
Bias stability (100s smooth -45°C~+70°C) ≤0.5°/h
Bias repeatability ≤0.1°/h
Random walk ≤0.01°/h1/2
Scale factor non-linearity ≤20ppm
Scale factor repeatability ≤10ppm
Dynamic range ±500°/s
Environmental Specifications
Parameter Value
Operate temperature -45°C～+70°C
Storage temperature -50°C～+80°C
KSGYR312F-L 3-Axis Fiber Optic Gyroscope 71.5×68×45mm ≤0.1°/h Bias
